Suspension Fork Mounts

From: £30.00

The SFM is a universal clamp system that enables suspension fork users to mount cargo or water bottle cages to the lower leg of the fork.

The SFM ship as a pair, allowing you to fit one side of your fork.



Free shipping over £150.00 30-day returns policy 5-year warranty

Specifications

Media Reviews

Top tip: Try searching for your bike make/model below to find others using this product on your bike.

Customer Reviews

Based on 215 reviews
87%
(187)
8%
(18)
4%
(8)
0%
(1)
0%
(1)
V
Valerio Stuart (GB)
Bike: Salsa Cutthroat, SID SL
Riding Style: Road / Ultra-endurance, Bikepacking, MTB, Commuting, Touring
Simply perfect

I took a leap of faith and tried the SFM at Atlas Mountain Race after a very short test ride. They didn't let me down and helped me carrying vital additional water bottle on the long race.

K
Karen Metcalfe (US)
Bike: Specialized Fuse
Riding Style: Bikepacking
Suspension Fork mounts

This product is incredibly awesome! Tedious and somewhat difficult to install. But it was worth it! Super solid and I feel very confident that they will stay in place. Getting the bolts to lineup was the hard part. Otherwise five stars.!!

Hi Karen,

Thank you for taking the time to leave a review for our Suspension Fork Mounts. We are pleased to hear that you find the product a good addition to your set up and that it provides a solid and secure fit.

Due to the technical nature of our products, we understand that installation can be sometimes be a bit tricky, but we are glad to hear that it was worth it.

We appreciate your feedback and we will definitely take note of your experience with aligning the bolts. Thank you for choosing our products.

Best,

Amy

A
Andy White (GB)
Bike: Sonder Broken Road
Riding Style: Bikepacking
Suspension fork mounts (carbon)

I bought the fork mounts for my sonder broken road mountain bike. After carefully sizing them up and fitting them, the carbon on one of the mounts started cracking and delaminating. I contacted tailfin immediately and they sent out another complete set. As I was putting these on the forks, another one cracked, even before I’d started tightening it up. Luckily tailfin had sent a pair so I was able to complete the setup. If I was ordering a new set I would go for the aluminium ones. Just my personal experience, tailfin were brilliant to deal with and had the issue resolved quickly.

123

FAQs

Weight is the key difference between the two different versions. The performance of both the Carbon and Stainless Steel SFM is comparable. The overall look of the two different materials is of course slightly different.

Currently forks with a leg diameter lower than 38mm or larger than 45mm are not accommodated. Luckily most modern suspension forks barring long travel forks such as Fox’s 38 or RockShox’s Zeb fall between the recommended dimensions.

Please note the SFM's are not compatible with the Fox 34 Step-Cast 2022/23 Fork (earlier models are compatible) OR the Fox 34 Float Performance Elite Fork. This is due to the raised section on the reverse of the fork legs

Just as if you overtighten your seatpost collar and find your dropper post performance hampered, exert too much clamping force to a thin walled suspension fork and performance can be compromised and potentially damage the sensitive internals. Through exhaustive testing we have created an accessory mount that requires minimal clamping force, thus minimising the risks to your expensive suspension fork.

The Tailfin SFM is unique in giving three different cage mounting points. If mounting a single cage you may choose any of the three. When mounting two cages you will need to use the two outside mounting positions. We suggest positioning the SFM at an angle that places cages as close to the fork as possible.

The Tailfin SFM is shipped as a pair. Giving you all you need to attach cages to ONE side of your suspension fork. Order TWO sets to fit cages to both sides of your fork.

The SFM has been designed to minimise the chance of scratching however with repeated fitting and removal slight scratching could occur. We recommend applying a thin layer of helicopter/self-amalgamating protective tape if you want to protect your decals fully. Remember to measure your SFM after the tape has been applied.

In order to ensure the complete and unrestricted performance of your suspension fork, it is highly important not to exceed the recommended maximum torque of 3Nm. As with any precision component, the use of a torque wrench is required for safe fitting.

Carbon fibre and stainless steel were chosen as materials for making the SFM as one of the key properties of both is the ability to resist an effect called 'creep'. Creep is an impact associated with products manufactured from polymeric materials (plastics) whereby any increased strain - even that under the recommended level. It occurs as a function of time through extended exposure to levels of stress that are below the yield strength of the material. Given sufficient time, this can lead to creep rupture, the failure within a material as a result of continuously applied stress at a level below the tensile strength.  Plastic materials are particularly prone to creep rupture through exposure to static stresses. Simple answer: carbon and steel SFMs will last longer and perform better than plastic counterparts.

Yes, as long as the diameter is within the 38-45mm. Lefty Ocho - yes, but you will need to clamp below the cable guide.

No, currently the SFM does not fit a Rudy fork, as the lower leg tapers too much.
